I.Usage:
It is the dominant glass ware forming machine in the word, dependable rotary with a single table, having 12 individual sections. Each section produces by press&blow with a single gob. This machine is suitable for glassware factories to produce many kinds of shapes of glassware, such as tumbler, goblet etc.
II. Main technical parameters:
1. Output: 36-64pcs/min;
2.Power of electric motor:7.5KW;
3.Overall dimensions:4.6mmⅹ4.0mmⅹ2.8mm;
4.Weight:14.5t;
III.Products to be blown:
1. Diameter:35-100mm;
2. Height:51-165mm;
3. Capacity:0.03-0.51L;
4. Weight of its products:30-500g.
H-28 Pressure blower
I. Usage:
It is the dominant glass ware forming machine in the word, dependable rotary with a single table, having 12 individual sections. Each section produces by press&blow with a single gob. This machine is suitable for glassware factories to produce many kinds of shapes of glassware, such as tumbler, goblet etc.
II. Main technical parameters:
1. Output: 36-64PCS/min;
2. Power of electric motor: 7.5KW;
3. Overall dimensions: 4.6mm*4.0mm*2.8mm;
4. Weight: 20t;
III. Products to be blown:
1. Diameter: 35-100mm;
2. Height: 51-170mm;
3. Capacity: 0.03-0.51L;
4. Weight of its products: 30-400g.
